220V Nema 42 3 Phase LC31115+LC3722A 12N.M Hybrid Stepper Motor And Driver Kit

Name: 220V Nema 42 3 Phase LC31115LC3722A 12NM Hybrid Stepper Motor And Driver Kit
Brand: LICHUAN
Price: 166.50 USD

Quality 220V Nema 42 3 Phase LC31115+LC3722A 12N.M Hybrid Stepper Motor And Driver Kit for sale

Model Number : LC31115+LC3722A

Brand Name : LICHUAN

Place of Origin : Guangdong, China

MOQ : 1 set

Price : $166.50 / set

Phase : 3

Shaft Diameter : 19MM(0.75in)

Torque : 12nm, 12N.M

Type : Hybrid

Current / Phase : 7.0A

Nema Frame Size : NEMA 42

Voltage : 220V

Warranty : 3 months ~ 1 year

Step Angle accuracy : ± 5% (whole step )

Resistance Accuracy : ± 10% (20℃)

Inductance Accuracy : ± 20% (1KHZ)

Temperature Rise : 80°C max (Rated current, 2-phase power)

Ambient Temperature : -20°C ~ +50°C

Insulation Resistance : 100M Min 500 VDC

Matched driver : LC3722A

Dielectric Strength : 500V AC 1 minute

Allowable Radial Load : 0.02mm Max (450g load)

Contact Now

Lichuan Nema42 220V 3phase LC31115+LC3722A 12N.M hybrid stepper motor and stepper driver kit

Packaging & Shipping

FAQ

1. Are you factory?

Yes, we are facotry, and we produce stepper motor/driver, Servo motor/driver and planetary reducer for more then 10 years in China. Lichuan is our registered brand.

2. How to select models?

Before purchasing, please contact us to confirm model No. and specifications to avoid any misunderstanding.

3. How do you ship the goods?

We normally ship goods by express(DHL/UPS/FEDEX/EMS), by sea and by air, also accept customer

4. Can I test sample?

Yes, sample charged can be offered for testing.

5. Can we be agent or distributor?

Yes, welcome and we will support you.

6. Can you do OEM or ODM service?

Yes, we have R&D department and accept OEM and ODM service.

7. How about warranty?

One year warranty, technical support available, we always try our best to help customers to solve problems
