Nema42 3ph AC 220V 20N.M Digital Display Closed Loop Stepper Motor Drive Kit

Name: Nema42 3ph AC 220V 20NM Digital Display Closed Loop Stepper Motor Drive Kit
Brand: LICHUAN
Price: 215.99 USD

Quality Nema42 3ph AC 220V 20N.M Digital Display Closed Loop Stepper Motor Drive Kit for sale

Model Number : LC110H3219+LCDA2260H

Brand Name : LICHUAN

Place of Origin : Guangdong, China

Certification : ce

MOQ : 1 set

Price : $215.99 / set

Phase : 3, 3-Phase

Type : Permanent Magnet, LC110H3219+LCDA2260H

Current / Phase : 7A

Warranty : 3 months ~ 1 year

Voltage : AC220V

Application : High Speed CNC Machine

Torque : 20N.M

Name : Nema42 closed loop stepper motor kit

motor current : 7A

Motor length : 219+22mm

PPR : 1000

Contact Now

Nema42 3ph AC 220V 20N.M Digital Display Closed Loop Stepper motor drive kit

Packing list for motor and drive with cable :

110 Nema42 servo closed loop motor one set		Qty
Nema41 closed loop hybrid servo stepper motor	LC110H3219	1pcs
Matched servo digital stepper driver	LCDA2260H	1pcs
With 3M Encoder cable line ,if you need more longer ,pls contact us .

Matched Driver for LCDA2260H

Parameter/Vaule	LCDA2260H
Parameter/Vaule	Minimum	Typical	Maximum	Unit
Max peak current	-	-	6	A
Input voltage	150	220	230	VAC
Logic input current	7	10	16	mA
Pulse frequency	-	-	200	KHZ

2. Interface definition:

Symbol	Name	Explanation
R	Power input terminal	150V~230VAC
S		150V~230VAC
NC		Empty terminal
BR1	External braking resistor	External braking resistor is connected between BR1 and P +
P+	Linear bus voltage	External braking resistor is connected between BR1 and P +

Symbol	Name	Explanation
U	Motor U phase winding	-
V	Motor V phase winding	-
W	Motor W phase winding	-
PE	Ground terminal	-
R S	Control power input	150V~230VAC

(2)Driver encoder CN3 terminal definition

(LCDA2260H encoder signal terminal with 15Pin DP header, pin defined as follows :)

Pin	Symbol	Color	Name
2	EB+	Yellow	Motor encoder B phase positive input
12	EB-	Green	Motor encoder B phase negative input
1	EA+	Black	Motor encoder A phase positive input
11	EA-	Blue	Motor encoder A phase negative input
13	VCC	Red	Encoder + 5V input
3	EGND	White	Encoder power ground

(3) Driver control terminal definition (44 pin DB plug)

Name	Explanation
PUL+	Pulse input signal: pulse effective edge adjustable, the default pulse rising edge is valid; in order to reliably respond to the pulse signal, the pulse width should be greater than 1.2μs. Such as the use of +12 V or +24 V when the need to string 3K resistance
PUL-
DIR+	Direction input signal: high / low level signal, in order to ensure reliable reversing of the motor, the direction of the signal should be preceded by pulse signal at least 5μs to establish, such as the use of +12 V or +24 V string 3K resistor.
DIR-
ENA+	Enable control signal: This input signal is used to enable or disable. When ENA +, ENA- have input, the drive will cut off the motor phase to make the motor in a free state. When this function is not required, the terminal can be left floating. Such as the use of +12 V or +24 V when the need to string 3K resistance
ENA-
Pend+	Positioning completion signal positive side
Pend-	Positioning completion signal negative
ALM+	Alarm output positive terminal
ALM-	Alarm output negative termina

Lichuan Driver LCDA2260H Panel Instruction :
